Breakthrough FEA Course Content List

Check what knowledge and skills will you gain in the course

Modules in the Course:

Module 0: How to learn here

  • Course Introduction
  • Guide on using the course

Module 1: Introduction to FEA

  • What is FEA for?
  • What does FEA do?
  • FEA Workflow
  • How to define a problem
  • What is important in FEA
  • Consistent unit system
  • Conclusion

Module 2: Important Engineering Concepts

  • What is stress
  • Normal stress and shear stress
  •  Stress in 3D
  • Equivalent stress
  • Hooke’s law
  • Structural rigidity
  • Stress concentrations
  • Active forces and reaction forces balance
  • Rigid body motion
  • Conclusion

Module 3: Model Preparation

  • Importing CAD geometry
  • Creating geometry in preprocessor
  • Benefits of simplifying the geometry
  • Model symmetry
  • How to define symmetry in FEA
  • Small details spoil mesh
  • How to connect beams to shells and beams/shells to solids
  • Rigid, hinged, semi-rigid connections in beam models
  • How to check if the connection is a hinge
  • How to calculate connection rigidity
  • Linear material properties
  • When linear material is not enough
  • Conclusion

Module 4: Model Supports

  • How to support your model
  • Rigidity of supports
  • Realistic boundary conditions
  • Why pinned supports can be rigid!
  • How to make an area support
  • What can and cannot be simplified
  • Boundary conditions and Hooke’s law
  • Linear contact – the basics
  • How to define linear contact
  • When it is possible to ignore contact?
  • Typical solutions for contact and BC:
    • Example 1: Cantilever
    • Example 2: Bolted connection
    • Example 3: Beam on area support
    • Example 4: Different rigidity supports
  • Conclusion

Module 5: Loads

  • Realistic load values and codes
  • Characteristic and design loads
  • Concentrated loads and reality
  • Force vs Moment
  • Gravity vs Pressure
  • Enforced deformations as load
  • Realistic load distribution:
    • Load distribution: Part 1
    • Load distribution: Part 2
    • Load distribution: Part 3
  • Conclusion

Module 6: Meshing

  • Basic element types:
    • Beam elements
    • Plate elements
    • Solid elements
    • Choosing element type
  • Higher order elements
  • TRI vs QUAD
  • TET vs HEX
  • Model Simplifications
  • RBE – Rigid Body Elements
  • Plain strain elements
  • Mesh refinement:
    • Mesh refinement: Case study
    • Mesh refinement: Challange 1
    • Mesh refinement: Challange 2
  • Mesh and Mathematics (M&M!)
  • Mesh Quality Measures
  • Conclusion

Module 7: Analysis

  • Analysis… let’s put your FEA solver to work!
  • Linear Analysis Setup
  • Solver vs pre/post processor
  • Linear Static Limitations
  • What does nonlinear material do?
  • What does nonlinear geometry do?
  • Contact
  • Beyond Linear Static
  • When it is safe to use linear static?
  • Model Checking
  • Troubleshooting
  • Conclusion

Module 8: Post-Processing

  • Post processing
  • Business advice first!
  • Stress/Strain/Displacement
  • The Stress Map!
  • Stress averaging
  • Issues with stability
  • Dealing with stress higher than yield
  • Strain as a measure of capacity
  • Deformations
  • Beams in FEA
  • Results verification
  • Verification with hand calculations!
  • Business side of the report
  • Technical side of the report
  • Conclusion

Example 1: Plate in tension

  • Geometry
  • Material properties
  • Boundary conditions
  • Loads
  • Meshing
  • Analysis
  • Post processing
  • Conclusion

Example 2: Bolted cantilever

  • Geometry
  • Material properties
  • Boundary conditions
  • Loads
  • Meshing
  • Analysis
  • Post processing
  • Conclusion

Example 3: Solid bracket

  • Geometry
  • Material properties
  • Boundary conditions
  • Loads
  • Meshing
  • Analysis
  • Post processing
  • Conclusion

Example 4: Roof rafter stability

  • Introduction: Stability design
  • Introduction: LBA
  • Introduction: LBA settings
  • Geometry
  • Supports / Loads / Mesh
  • Initial stability calculations
  • Critical bending moment calculation
  • Critical bending moment in design
  • Bracing influence on stability
  • Developing model further – part 1
  • Developing model further – part 2
  • Verifying assumptions about bracings
  • Conclusion

Example 5: Street lamp

  • Geometry
    • Base: Part 1
    • Base: Part 2
    • Post: Part 1
    • Post: Part 2
    • The top part
  • Materials + Properties
  • Meshing
    • Base plate
    • Base plate: “Bonus” video
    • Lamp post
    • Top part
  • Loads
    • Wind load according to EN 1991-1-4
    • Loading the model
  • Boundary conditions
  • Avoiding contact with line supports
  • Dealing with stress concentrations
  • Defining contact
  • Analysis
  • Post processing
    • Deformations
    • Stress
    • Stability
    • Summary
  • Conclusion
